| Model |
CB730 |
CB1300 |
| Media Way |
M bracket or Stand |
Floor Stand |
| Mainboard |
8MB Memory, 32 bit processor |
| Control Panel |
Highlight patterned LCD ,Friendly operating keypad |
| Driver |
Double high torsional force motor, micro-step driver |
| Max paper feed width |
730mm |
1300mm |
| Max cutting width |
700mm |
1270mm |
| Max cutting speed |
500mm/s |
| Max cutting length |
20000mm |
| Max cutting thickness |
1.0mm |
| Cutting force |
0-400g(digital adjustment) |
| Mechanical precision |
0.05mm |
| Repeatable precision |
≤0.1mm/twice(On 1000*1000mm square) |
| Protocol |
Compatible DM/PL,HP/GL |
| Interface |
Blue tooth/USB Port/Serial Port/D Card |
| Power Supply |
INPUT AC110V±10% 1.0A 60Hz,AC220V±10% 0.5A 50Hz |
| Packing size |
1045*300*330mm |
1595*300*415mm |
| Gross Weight |
24Kg |
29Kg |
